ZBOX MAGNUS EN275060TC, Intel® Core™ Ultra 7-255HX, 2x DDR5 SO-DIMM, 2x M.2 NVMe SSD, NVIDIA® GeForce RTX™ 5060 Ti 16GB Graphics Card, Barebone Mini Gaming PC
- SKU: 19933972
- Manufacturer: ZOTAC
- MPN: ZBOX-EN275060TC-U
- Availability: USUALLY SHIPS WITHIN 1-3 WEEKS
ZBOX MAGNUS EN275060TC, Intel® Core™ Ultra 7-255HX, 2x DDR5 SO-DIMM, 2x M.2 NVMe SSD, NVIDIA® GeForce RTX™ 5060 Ti 16GB Graphics Card, Barebone Mini Gaming PC
The MAGNUS EN275060TC is the first model in the MAGNUS EN Series to feature a full-fledged desktop GeForce RTX Graphics card in its tiny 2.65 Liters chassis. With a 20-Core Intel Core Ultra processor and a GeForce RTX 5060 Ti 16GB GDDR7 graphics card, this mini PC outperforms most computers of its size, and excels at gaming, creative tasks, or even localized AI deployment.
The MAGNUS EN275060TC is the first model in the MAGNUS EN Series to feature a full-fledged desktop GeForce RTX Graphics card in its tiny 2.65 Liters chassis. With a 20-Core Intel Core Ultra processor and a GeForce RTX 5060 Ti 16GB GDDR7 graphics card, this mini PC outperforms most computers of its size, and excels at gaming, creative tasks, or even localized AI deployment.
- Intel Core Ultra 7 Processor 255HX
- Desktop GeForce RTX 5060Ti 16GB GDDR7 GPU
- Up to 96GB DDR5-6400 CSODIMM/DDR5-5600 SO-DIMM Memory support
- Overall up to 792 AI TOPs
- 2 x M.2 NVMe PCIe 4.0 x4 SSD slots
- Up to quad-display support
- Fast data transfer with dual Thunderbolt 4 and USB 3.2 Gen2 (10Gbps, Type-A)
- Dual 2.5Gbit LAN, WiFi 7, Bluetooth 5.4
- Creator ready, Game ready, VR ready, AI ready
- Compact 2.65 liter size, slim 62.2mm / 2.45in height
- Wall mount ready
- Windows 11 Ready
| Computing System | |
| Processor | Intel Core Ultra 7 Processor 255HX (20 Cores, 2.4 GHz up to 5.2 GHz) |
| Chipset | Intel, NVIDIA |
| System Memory | 2 x DDR5-6400 CSODIMM/DDR5-5600 SO-DIMM Memory slots (up to 96GB) |
| Graphics | |
| Graphics Engine | NVIDIA GeForce RTX 5060 Ti GPU (16GB GDDR7 128-bit) |
| Video Output |
1 x HDMI® Connector (Supports 4K 480Hz HDR or 8K 120Hz HDR with DSC, and Gaming VRR as specified in the HDMI 2.1b Specification) 3 x DisplayPort 2.1b with UHBR20 (up to 4K 480Hz or 8K 165Hz with DSC) Up to Quad Display Support |
| Storage | |
| Hard Drive | N/A |
| Mass Storage | N/A |
| Optical Drive | N/A |
| mSATA | N/A |
| M.2 | 1 x M.2 NVMe PCIe 5.0 x4 SSD slot (2280), 1 x M.2 NVMe PCIe 4.0 x4/SATA SSD slot (2280) |
| Card Reader | N/A |
| I/O Ports | |
| Audio | Microphone / Headphone combo port, 8ch via HDMI |
| USB Port | 5 x USB 3.2 Gen2 (10Gbps, Type-A) |
| LAN | 2 x 2.5Gbps Ethernet (10/100/1000/2500Mbps) |
| Antenna | Dual WiFi SMA connector |
| Wifi | WiFi 7 |
| Bluetooth | Bluetooth 5.4 |
| Legacy I/O | N/A |
| CIR Infrared Port | N/A |
| Thunderbolt | 2 x Thunderbolt 4 |
| USB | N/A |
| IDE | N/A |
| VGA | N/A |
| Mechanical | |
| Kensington Lock | Yes |
| LED Indicators | Power, HDD, Wi-Fi |
| Power Supply | AC-DC Adapter O/P: 20V/330W |
| Cooling system | Fan + Heatsink |
| ZBOX Dimensions | 210mm x 203mm x 62.2mm (8.27in x 7.99in x 2.45in) |
| Case Mounting | Wall mount ready |
| Miscellaneous | |
| Supported OS | Windows 11 Ready |
| Accessories |
2 x WiFi antenna AC Adapter Power Cord (quantity and type dependent on region) Warranty Card Quick Start Guide Wall Mount Brackets (1 pair) with screws USB Flash drive with OS Drivers |
| Available SKU | |
| Available SKU | ZBOX-EN275060TC-U |
