TR200, Mesh Panel, LCD, No PSU, microATX, Snow, Mini Tower Case
- SKU: 20216543
- Manufacturer: THERMALTAKE
- MPN: CA-11L-00S6NN-01
- Availability: USUALLY SHIPS WITHIN 3-5 DAYS
TR200, Mesh Panel, LCD, No PSU, microATX, Snow, Mini Tower Case
Designed to perform as a compact mid tower while still offering plenty of space to build the TR300 merges a small footprint with a full-size PC. In terms of space the TR300 can fit ATX/mATX/mITX motherboards, 410mm GPUs, 360mm radiators, and up to eight 120mm fans. For an extra upgrade there is the 6.0 inch LCD Screen Kit preinstalled for custom pictures, GIF, and even real-time system info.
Designed to perform as a compact mid tower while still offering plenty of space to build the TR300 merges a small footprint with a full-size PC. In terms of space the TR300 can fit ATX/mATX/mITX motherboards, 410mm GPUs, 360mm radiators, and up to eight 120mm fans. For an extra upgrade there is the 6.0 inch LCD Screen Kit preinstalled for custom pictures, GIF, and even real-time system info.
-
Portable Micro-ATX Design with Full-Size Hardware Support
Built for Micro-ATX and Mini-ITX systems with room for up to 365mm GPUs, 175mm CPU coolers, and 258mm PSUs. -
Flexible Cooling Layout
Supports up to seven 120mm fans and up to a 360mm top radiator for high-airflow or liquid-cooled builds. -
5.25” Expansion Ready
Adds support for optical drives, hot-swap storage, fan controllers, or other 5.25” accessories. -
Smart Personalization Ready
Upgrade with the optional 6.0” LCD Screen Kit to display system stats, custom images, and GIFs through TT RGB PLUS 3.0. -
Build-Friendly Convenience
Features easy-access panels, removable dust filters, and an adjustable GPU support brace for easier building and maintenance.
| P/N | CA-11L-00S6NN-01 |
| Series | TR Series |
| Case Type | Micro Case |
| Dimensions | 364 x 220 x 494 mm (14.33 x 8.66 x 19.45 inch) |
| Side Panel | Steel |
| Color | Snow |
| Material | SPCC |
| Cooling System | Rear(exhaust): 120 x 120 x 25 mm Standard fan (1400rpm, 23.2 dBA) x 1 |
| Expansion Slots | 5 |
| Motherboard | 6.7" x 6.7" (Mini ITX), 9.6" x 9.6" (Micro ATX) |
| I/O Port | USB 3.2 (Gen 2) Type-C x 1, USB 3.0 x 2, HD Audio x 1 |
| PSU | Standard PS2 PSU (optional) |
| Fan Support | Top: 3 x 120mm |
| Radiator Support | Top(AIO) : 1 x 360mm, 1 x 240mm, 1 x 120mm 1 x 280mm, 1 x 140mm Rear(AIO) : 1 x 120mm |
| Clearance | CPU cooler height limitation: 175mm VGA length limitation: 365mm PSU length limitation: 258mm |
