RS42407-CR800.OLE.R, 24x 3.5"/2.5" External Bays, 2x 2.5" Rear External Bays, No PSU, EEB, Black/Grey, 4U Chassis - TAA Compliant
Quantity:
- SKU: 18604558
- Manufacturer: InWin
- MPN: RS42407-CR800.OLE.R
- Availability: TEMPORARILY OUT OF STOCK
Starting At
$1,981.61
| Industry Standard | Compatible with EIA-RS310D standard 19" cabinets |
| M/B Form Factor | ATX(12" x 9.6"), CEB(12" x 10.5"), EEB(12" x 13") |
| Drive Bay |
• External 2.5"/3.5" hot-swap trays x 24 (optional U.2 NVMe SSD tray x 8) • Rear 2.5" hot-swap trays x 2 (supports SAS 12Gbps) |
| Power Supply |
Supports: • Form factor: 80 Plus Platinum CRPS • Watt: 550W/800W/1200W/1600W |
| Indicators | Power LED, LAN1/LAN2/LAN3/LAN4 LED, system LED, ID LED, HDD LED |
| Front Control Panel | Power on/off, reset, NMI, ID SW, USB3.0x2 |
| Backplane Type-1 |
• Host: Mini-SAS HD (SFF-8643) x 3, Slimline (SFF-8654) x 8 • HDD: SAS/SATA x 24 or SAS/SATA x 16 and NVMe SSD x 8 |
| Backplane Type-2 |
• Host: Mini-SAS HD (SFF-8643) x 3, OCuLink (SFF-8611) x 8 • HDD: SAS/SATA x 24 or SAS/SATA x 16 and NVMe SSD x 8 |
| 12Gbps Expander Module | Broadcom SAS 35 x 36R expander |
| Cooling Fans | 80 x 38mm PWM hot-swap fans x 4, 12000RPM |
| Expansion Slot | Full-height PCIe slots x 7 |
| Material |
• Material: SGCC • Thickness: 1.2mm |
| Rail Kit | Supports 30" ball-bearing slide rail |
| Product Dimensions (DxWxH; Chassis Only) |
660 x 448 x 172.8mm (26" x 17.6" x 6.8") |
| Package Dimensions (DxWxH) | 920 x 610 x 338mm |
| Weight (Chassis Only) |
• Net weight: 18.97kg • Gross weight: 23.15kg |
| Cubic Feet | 6.7 |
| Container Information |
Single packing with pallets: • 20': 100pcs • 40': 210pcs • 40'HQ: 252pcs |
|
* InWin NVMe backplane supports PCIe Gen4 data transfer speed, the actual speed will be determined by MB and HDD specifications. * All components and optional parts are not included. In Win Development Inc. reserves the right to make final modifications. |
|
