RM53-502 5U Rackmount Chassis, 360mm AIO Support, 2x 5.25", 1x 3.5", 5x 2.5", Black
- SKU: 19368468
- Manufacturer: SILVERSTONE
- MPN: RM53-502
- Availability: USUALLY SHIPS WITHIN 1-3 WEEKS
Price
$635.94
- Supports up to SSI-EEB motherboards
- Universal hard drive cage design supports 5.25", 3.5" and 2.5" storage devices
- Supports 360mm liquid cooling radiator
- Security lock fitted on the front removable door
- Dual PSU support for PS2 (ATX)+SFX PSU, Mini Redundant, or 2U CRPS Redundant
- Upright or horizontal placement flexibility
- 8 PCI expansion slots
- Provides additional cooling solutions for graphics cards
| Model No. | SST-RM53-502 |
| Chassis form factor | 5U |
| Motherboard | SSI-EEB, SSI-CEB, Extended ATX, ATX, Micro-ATX, Mini-ITX |
| Material | Steel |
| Drive Support |
External: 5.25" x 2 (compatible with 2.5" x 4 or 3.5" x 2) Internal: 3.5” x 1 (compatible with 2.5” x 2) 3.5” x 2 (compatible with SFX PSU x 1) 2.5” x 5 (two expansion cards occupy the 8th slot position) |
| Cooling system |
Front: 120mm x 3, 80mm x 3 (2 x 80mm fans included) Rear: Rear I/O: 120mm x 1 / 140mm x 1 (1 x 140mm fans included) Rear fan cage: 80mm x 2 |
| Radiator support |
Front: 120mm / 240mm / 360mm Rear: 120mm |
| Limitation of CPU cooler |
Single CPU: 178mm Dual CPU: 101–178mm * |
| Expansion Slot | 8 |
| Limitation of expansion card |
Length: 454mm (without installing front fans, radiators) Width: w/ GPU holder: 160mm ; w/o GPU holder: 185mm |
| Power Supply |
Primary PSU slot: PS2 (ATX) / Mini Redundant / 2U CRPS Redundant Secondary PSU slot: SFX (occupies 3.5" bracket) |
| Limitation of PSU |
Primary PSU slot: 190mm (Removal of 3.5" drive cage eliminates PSU depth limitation) Secondary PSU slot: 130mm |
| Front I/O Port |
USB Type-C x 1 USB 3.0 x 2 |
| LED Indicators |
Power status x 1 HDD activity x 1 LAN activity x 2 |
| Dimension |
Incl. rear fan cage: 440mm (W) x 220mm (H) x 530mm (D), 51.3 liters Excl. rear fan cage: 440mm (W) x 220mm (H) x 485mm (D), 46.95 liters |
| Net Weight | 11.47 kg |
| Extra |
Side switch for chassis intrusion security * For dual CPU cooler installation, please refer to the manual for detailed limitations. |
