Q14, 30mm Height, 115W TDP, Copper/Aluminum CPU Cooler
- SKU: 19280539
- Manufacturer: DYNATRON
- MPN: Q14
- Availability: USUALLY SHIPS WITHIN 1-3 WEEKS
Price
$37.75
Q14, 30mm Height, 115W TDP, Copper/Aluminum CPU Cooler
The Dynatron Q14 CPU cooler is designed for Q14- 1.5U version of U8
The Dynatron Q14 CPU cooler is designed for Q14- 1.5U version of U8
| CPU Support | Intel |
| CPU Socket | LGA 1700 |
| Screw Type | M3 |
| Installation Torque | 5-7 in-lb |
| Solution | 1.5U Server |
| Dimensions | 93.5 x 95.0 x 30.0 mm |
| Weight | 348g (Fan + Heatsink) |
| Material | Copper Base & Aluminum Fins with Heat Pipe Embedded |
| Fan Dimension | 92.0 x 92.0 x 12.0 mm |
| Speed |
At Duty Cycle 0~20%: 800±200 RPM At Duty Cycle 50%: 1900±10% RPM At Duty Cycle 100%: 3200 RPM |
| Bearing | Double Ball |
| Rated Voltage | 12V |
| Power |
At Duty Cycle 0~20%: 0.2 W At Duty Cycle 50%: 0.5 W At Duty Cycle 100%: 1.6W |
| Air Flow |
At Duty Cycle 0~20%: 9.88 CFM At Duty Cycle 50%: 21.38 CFM At Duty Cycle 100%: 35.78 CFM |
| Noise Level |
At Duty Cycle 0~20%: 22.3 dBA At Duty Cycle 50%: 26.1 dBA At Duty Cycle 100%: 36.2 dBA |
| Static Pressure |
At Duty Cycle 0~20%: 0.28 mm-H2O At Duty Cycle 50%: 1.22 mm-H2O At Duty Cycle 100%: 3.21 mm-H2O |
| Lead Wire Pin Out |
Pin#1- Black(-) Pin#2- Black (+) Pin#3- Black (Tachometer/ Signal Output) Pin#4- Black (PWM) |
|
Life – Continuous operating under normal temperature (40 °C or 104 °F) |
70,000 Hours |
