| Heatsink Specifications | |
| Dimension: | L125 mm x W110 mm x H155 mm(Without Fan) |
| Heat pipes: | 6mm heatpipe x 6 units |
| Copper Base: | C1100 Pure copper nickel plated |
| Intel: | LGA115X/1200/1700/1851 |
| AMD: | AM4/AM5 |
| TL-C12C-X28 V2 FAN Spec | |
| Dimension: | L120 mm x W120 mm x H28 mm |
| Rated Speed: | 1850 RPM±10% (MAX) |
| Noise Level: | 29.5 dBA |
| Air Flow: | 88.89 CFM (MAX) |
| Air Pressure: | 2.21 mm H2O (MAX) |
| Ampere: | 0.30 A |
| Connector: | 4 Pin (PWM Fan connector) |
| Bearing Type : | S-FDB Bearing |
