PL070X.B3, 5x 3.5"/2.5" Internal Bays, No PSU, EEB, Black, Mid Tower Chassis - TAA Compliant
Quantity:
- SKU: 18512112
- Manufacturer: InWin
- MPN: PL070X.B3
- Availability: TEMPORARILY OUT OF STOCK
Starting At
$300.14
| M/B Form Factor | ATX(12" x 9.6"), CEB(12" x 10.5"), EEB(12" x 13") |
| Drive Bay |
Internal: • 2.5"/3.5" trays x 5 • optional 2.5" drives x 4 (1 x 9mm, 3 x 15mm) |
| Power Supply |
Supports: • 1250W PS2 single PSU, 80 Plus Gold, length up to 250mm (including cable management area) • 1600W 2U 1+1 CRPS, 80 Plus Platinum |
| Indicators | Power status, HDD, LANs, system fail activity LEDs |
| Front Control Panel | Power switch, system reset, USB 3.0 x 2 |
| Chassis Security |
Supports: • Padlock loop and Kensington lock slot • Intrusion switch (optional) |
| Cooling Fans |
• Front: 120 x 25mm PWM fan x 2 (one pre-installed) • Middle: 120 x 25mm PWM fan x 2 (one pre-installed) • Rear: 120 x 25mm PWM fan x 1 (pre-installed) or 80 x 38mm PWM fan x 2 (optional) |
| Water Cooling Kit |
AIO liquid coolers support: • Top 240mm, middle 240mm or 360mm radiator x 1 • Built-in 240mm top radiator bracket x 1 |
| Expansion Slot | Full-height PCIe slots x 7 |
| Material |
• Material: SECC • Thickness: 0.8~1.0mm |
| Maximum Capacity |
• GPU length: Middle radiator installed: 350mm Middle fans installed: 365mm • CPU heatsink height: 145mm • PS2 power length: 250mm (including cable management area) |
| Product Dimensions (DxWxH; Chassis Only) |
560.2 x 200 x 430.1mm (22.1" x 7.9" x 16.9") |
| Package Dimensions (DxWxH) | 720 x 592 x 340mm |
| Weight (Chassis Only) |
• Net weight: 11.72kg • Gross weight: 14.80kg |
| Cubic Feet | 5.12 |
| Container Information |
Single packing with pallets: • 20': 110pcs • 40': 240pcs • 40' HQ: 288pcs |
|
* The actual product is subject to change without prior notice. In Win Development Inc. reserves the right to make any final modifications. * The above image is for reference only. All hardware components and optional parts are not included. |
|
