| Essentials |
| Product Collection |
Intel® Wi-Fi 7 Series |
| Marketing Status |
Launched |
| Launch Date |
Q3'23 |
| Weight (in grams) |
2230: 3.07+/-0.15g 1216:0.75+/-0.04g |
| Operating Temperature Range |
0 °C to 50 °C |
| Max Operating Temperature |
50 °C |
| Minimum Operating Temperature |
0 °C |
| Supported Operating Systems |
Windows 11* | Windows 10* | Linux* |
| Antenna |
2x2 |
| Supplemental Information |
| Product Brief |
View now |
| Networking Specifications |
| TX/RX Streams |
2x2 |
| Bands |
2.4GHz | 5GHz and 6GHz |
| Max Speed |
5.8 Gbps (320MHz | 4096QAM) |
| Wi-Fi CERTIFIED* |
Wi-Fi7 |
| Bluetooth Version |
5.4 |
| Package Specifications |
| Board Form Factor |
M.2 2230 | M.2 1216 |
| Package Size |
22mm x 30mm x 2.4mm | 12mm x 16mm x 1.7(+/-0.1)mm |
| System Interface Type |
M.2: PCIe* | USB |
