| Model |
ATHENA E5M |
| Case Type |
Micro Tower |
| MB Support |
Micro-ATX, Mini-ITX |
| Synchronization |
5V 3-Pin Addressable Header |
| CASE Color |
Black |
| Expansion Slots |
5 |
| Material |
SPCC & ABS & Tempered glass |
| Window |
Left |
| Radiator Support |
Top: 360mm, 280mm Rear: 120mm |
| Fan Support |
Top: 3 x 120mm , 2 x 140mm / Rear: 1 x 120mm / Bottom: 3 x 120mm |
| Pre-installed Fans |
Rear: 1 x 120mm ARGB Fan / Front: 3 x 120mm ARGB Fans |
| Drive Bays |
1 x 3.5 + 1 x 2.5 |
| I/O Port |
Type-C x 1, USB 3.0 x2, HD Audio x1, ARGB Switch x1 |
| Clearance |
CPU cooler height limitation: 165mm VGA length limitation: 400mm PSU length limitation: 150mm |
| Dimension (L x W x H) |
438 x 210 x 417mm |
