Specifications |
6 TB |
Standard Model Numbers |
ST6000VX001 |
SkyHawk™ Health Management Included |
Yes |
Interface |
SATA 6 Gb/s |
Features and Performance |
Drive Bays Supported |
Up to 16 |
Cameras Supported |
Up to 64 |
RV Sensors |
Yes |
Max. Sustained Transfer Rate OD (MB/s) |
180MB/s |
Cache (MB) |
256 |
Reliability/Data Integrity |
Tarnish Resistant |
Yes |
Load/Unload Cycles |
300,000 |
Non-recoverable Read Errors per Bits Read, Max |
1 per 10E14 |
Power-On Hours per Year (24×7) |
8,760 |
Workload Rate Limit (WRL) |
180 |
MTBF |
1,000,000 hr |
Warranty, Limited (years) |
3 |
Power Management |
Startup Current, Typical (12V, A) |
1.8 |
Average Operating Power (W) |
5 W |
Idling Average (W) |
3.4 W |
Standby Mode/Sleep Mode, Typical (W) |
0.25/0.25 |
Voltage Tolerance (5 V) |
±5% |
Voltage Tolerance (12 V) |
±10% |
Environmental/Temperature |
Operating (ambient, min °C) |
0 |
Operating (drive case, max °C) |
70 |
Non-operating (ambient, min °C) |
-40 |
Physical |
Height (mm/in, max) |
26.11 mm/1.028 in |
Width (mm/in, max) |
101.85 mm/4.01 in |
Depth (mm/in, max) |
146.99 mm/5.787 in |
Weight (lb/g) |
610 g/1.345 lb |
Carton Unit Quantity |
20 |
Cartons per Pallet / Cartons per Layer |
40/8 |
